Gas Fire | GD1

With its minimalist lines and dramatic flame pattern, the innovative GD1 indoor gas fire creates a modern and stylish focal point for your home. Choose from three sizes with three firebed options to create the perfect living space ambience. Powered direct venting allows you to run flues vertically or horizontally so you can place the GD1 almost anywhere you desire.

Architecturally-inspired minimalist design
Stunning flame effect
Super-efficient with low running costs
Hand-crafted firebed options
Stress-free wall switch operation
Optional remote control

Specification | GD1

The GD1 gas fire is available in three sizes: 1200, 1500 & 1600, with three firebed options.

	1200	1500	1600
Gas Type: Natural Gas or LPG	✔	✔	✔
Gas Controller Pack: Sit Sigma regulator & Sit controller	✔	✔	✔
Gas Connection: 3/8 soft copper pipe (3/8 flare provided with gas controller)	✔	✔	✔
Natural Gas Input: (MJ/h on high setting)	20	22	35
LPG Input: (MJ/h on high setting)	20	20	30
Estimated Heat Output: (kW on high setting)	7.8	9.2	10
Power Supply: 230V 50Hz	✔	✔	✔
Fixing Type: 2 x M5 bolts through base frame slots into the floor (adjustable)	✔	✔	✔
Flue Termination: Vertical or horizontal	✔	✔	✔
Clearances: 25mm from combustible materials and 5mm from non-combustible	✔	✔	✔
Flue Size: 100-150mm	✔	✔	✔
Warranty: 5 years on firebox, 2 years on other components	✔	✔	✔
